MAINTENANCE
INTELLI-GRIP® DIAGNOSTIC CODES
Refer to the following table when a diagnostic code appears on the LCD screen. Codes are listed
in alphanumeric order. If the Explanations/Directions do not resolve the issue, contact qualified
service personnel. All relevant parts are listed in “REPLACEMENT PARTS”.
= buzzer sounds = buzzer sounds continuously = strobe light flashes
Key:
Code On-Screen Message
Buzzer
Pattern
Strobe
Light
Activity
Explanations/Directions
B00
“Low 12V Battery (#)”
1 chirp every
2 seconds
(none)
Charge 12V battery
or, if necessary, replace it (see “12-
V
OLT BATTERY RECHARGE”). Cold battery may need to be
warmed and/or charged more often.
B01 “Lockout (low 12V battery) (#)”
continuous (none)
Once “Power Save” mode is activated, “attach” and
“release” functions are prevented because 12V battery
energy is insufficient. Charge battery before next lift (see
“12-V
OLT BATTERY RECHARGE”).
B02 “Replace 12V battery?”
1 chirp per
minute
(none)
Check condition of 12V battery
(see “Checking the 12-Volt
Battery” and “12-V
OLT BATTERY RECHARGE”). Since cold
battery may prematurely activate this notification, warm
battery and retest when appropriate. Replace battery as
needed.
Note: This notification can be
activated in error if battery
charger is plugged into power source while lifter is
powered up. If so, power down lifter, disconnect charger
from power source, and power up again. If code persists,
check battery condition as directed above.
B03
“Charge 12V battery soon”
1 chirp per
minute
(none) Charge 12-volt battery
(see “12-VOLT BATTERY RECHARGE”).
B09 “Replace 9V battery?”
1 chirp per
minute
(none)
Replace 9V battery for notification buzzer as needed (see
“N
OTIFICATION BUZZER BATTERY REPLACEMENT”).
C00 “Fail-safe on module”
continuous on
Fail-safe mode has been activated, to prevent potential
injury. Service is required.
C011
“Communication failure, module
1”
fast chirp (none) If code does not clear automatically, service is required.
C021 “Internal error, module 1”
continuous (none) If code does not clear automatically, service is required.
C04
“Module revision not
compatible”
1 chirp every
2 seconds
(none)
Make sure lifter is used within Operating Temperatures
(see “SPECIFICATIONS”). Then power lifter down and up
again. If code persists, service is required.
C05
“Module revision lockout”
continuous
(while button
is held)
(none)
Once “Power Save” mode is activated, “attach” and
“release” functions are prevented in connection with Code
C04. Service is required.
C06
“Control head revision not
compatible”
1 chirp every
2 seconds
(none)
Incompatible version of software was installed or Intelli-
Grip® control unit has failed. Service is required.
