wtw pH 3110 - Socket Field

Overview pH 3110
8
ba75791e02 11/2008
1.3 Socket field
Caution
Only connect sensors to the meter that cannot return any voltages
or currents that are not allowed (> SELV and > current circuit with
current limiting).
Almost all customary sensors fulfill these conditions.
Connectors:
1 pH electrode
2 Reference electrode
3 Temperature sensor
4 Service interface
4
1
2
3
