FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
Installation Manual
Page 4 of 56 Publication No. 150-049106
P-2000 Installation Manual Rev. F
Nov 2007
CHARACTERISTICS DESCRIPTION
Encryption Options AES/DES/DES-XL/DES-OFB/DVP/DVI
OTAR Options MDC1200 OTAR, P25 OTAR
Trunking Options Smartnet, Smartzone, P25
Receiver Specifications
Modes FM, P-25, P-25 Trunking, Motorola 3600 Baud Trunking
Sensitivity
Analog (12 dB SINAD) Better than .4 uV (-115 dBm)
Digital (5% BER) Better than .4 uV (-115 dBm)
Quieting
Analog (20 dB SINAD) .6 uV (-111.5 dBm)
Digital Not Applicable
Selectivity
Analog (12.5 kHz) -65 dB (NTIA Version: -70 dB)
Analog (25.0 kHz) -70 dB (NTIA Version: -80 dB)
Intermod Rejection
Analog (12.5) -70 dB
Analog (25.0) -70 dB
Spurious Rejection
Analog (12.5 kHz) -65 dB (NTIA Version: -70 dB)
Analog (25.0 kHz) -70 dB (NTIA Version: -85 dB)
Digital (5% BER) -70 dB (NTIA Version: -85 dB)
Unwanted Emissions
Narrow Band -60 dBm
Wide Band -60 dBm
Audio Output
Headset Out 100 Mw into 600 ohms
Normalized Out 1.0 Vrms into 10k Load
External Speaker Out 1.0 Vrms into 10k Load
Audio Distortion < 5% at Maximum Audio Output
Hum and Noise
Unsquelched <-35 dB
Squelched <-60 dB
Transmitter Specifications
Duty Cycle 25% at Full Power
RF Power Output 10 Watt Hi, 1 Watt Lo (2.75/1 Watt 700/800 MHz Bands)
Frequency Stability ± 1.5 PPM
Modulation Limiting:
12.5 kHz Channels ±2.5 kHz
20.0 kHz Channels ±4.0 kHz
25.0 kHz Channels +5.0 kHz
Unwanted Emissions < -70 dBc (-70 dBc Harmonics, -85 dBc Spurious)
Hum and Noise (Narrow Band) -35 dB
Hum and Noise (Wide Band) -40 dB
Residual FM 100 Hz Std
Microphone Audio Response .25 VMRS into 150 ohm Carbon or Carbon Equivalent
Transmit Distortion < 5%. @ 1 kHz
Sidetone Fidelity 6 dB max variation, 350 Hz to 2500 Hz
Sidetone Output Adjustable -3db below rated audio output
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.
