Wulfsberg FLEXCOMM 2000 - Antenna Options; RT-2000 Mounting Tray; Required Accessories

FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
INSTALLATION MANUAL
Publication No. 150-049106 Page 11 of 56
Rev. F P-2000 Installation Manual
Nov 2007
D. Antenna Options
The following antennas are recommended for use with the P-2000/RT-2000 Transceivers.
Antenna
Name
Wulfsberg Part
Number
Frequency Band FAA
Certification
Comant
Part Number
Antenna
Color
AT-695 121-0019-000 137-174 MHz TSO CI-177-2 White
AT-462 121-014378-01 406-512 MHz PMA CI-275-5 White
AT-462 121-014378-02 406-512 MHz CI-275-5-1 Black
AT-806 121-049075-01 806-960 MHz TSO CI-310-22 White
AT-806 121-049075-02 806-960 MHz TSO CI-310-22-4 Black
See Figure 2-5, 2-6, 2-7 for outline drawings of antennas.
E. RT-2000 Mounting Tray (Wulfsberg P/N 300-049065-01)
See Figure 2–4 for outline drawing of RT-2000 Mounting Tray.
F. Required Accessories
Part Type Part Description Wulfsberg
P/N
Alternative P/N
Connector Kit DB-25 Connector/Hardware/Pins 149-249093-25 N/A
Connector Component DB-25 Connector 030-02703-0000 Positronics, RD25FIOJVL-14
Connector Component DB-25 Backshell Hardware 129-241803-25 Norcomp, 994-025-030-121
Connector Component DB-25 Slide Lock Hardware 129-141470-25 AMP, 745584-3
Connector Component Crimp Pins 030-01157-0011 Positronics, FC602OD-14
Connector Kit DB-15 Connector/Hardware/Pins 149-249093-15 N/A
Connector Component DB-15 Connector 129-217927-01 Positronics, RD I 5FOO00C
Connector Component DB-15 Backshell Hardware 129-241803-15 Norcomp, 994-015-030-121
Connector Component DB- 15 Slide Lock Hardware 129-141470-15 AMP, 745584-1
Connector Component Crimp Pins 030-01157-0011 Positronics, FC602OD-14
RF Connector Straight TNC for RG-142/400 129-041810-01 AMP, 31-2373
Mil M23329/4-02,4-05
RF Connector Right Angle TNC for RG-142/400 129-041811-01 AMP, 31-2381
RF Connector Straight BNC for RG-142/400 129-049080-01 AMP,31-326
Mil M23329/3-02,3-05
RF Connector Right Angle BNC for RG- 142/400 129-049081-01 AMP, 31-334
RF Connector Straight "N" for RG-142/400 129-049112-01 AMP, 82-4427
M39012/01-0502
RF Connector Right Angle "N" for RG- 142/400 129-049113-01 AMP, 82-5374
Cable RT-2000 KVL/Data Cable 124-049082-01 N/A
Software XTS-3000 CPS and Tuner Software N/A ***
Software XTS-5000 CPS and Tuner Software N/A ***
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.
