FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
Installation Manual
Page 44 of 56 Publication No. 150-049106
P-2000 Installation Manual Rev. F
Nov 2007
4. Pin - Signal Name (J101 25 Pin D-sub)
1 - Headset 1 Out H
This analog output provides the High side of the receive and sidetone audio output from either
FM-1 transceiver (Mode 2) or the summation of FM-1 and FM-2 (Single Mic mode). Standard
audio levels of 100 mW into 600 ohm load is provided for standard modulation (1.0 kHz tone, 3
kHz FM Mod). This output is normally sent an audio panel. This output must use shielded wire.
2 - Headset 1 Out L
This analog output provides the Low side of the receive and sidetone audio output from a
transceiver. Normally this output is either grounded or sent to an audio panel. This output must
use shielded wire.
3 - CAN Data H
This bi-directional pin provides for data communications between a C-2000 and P-2000 or RT-
2000. Voltage levels range between 0 and 5 Vdc. This pin is only used when a system
incorporates a C-2000. Twisted Shielded wire should be used with this pin.
4 - CAN Data L
This bi-directional pin provides for data communications between a C-2000 and P-2000 or RT-
2000. Voltage levels range between 0 and 5 Vdc. This pin is only used when a system
incorporates a C-2000. Twisted Shielded wire should be used with this pin.
5 - External Speaker Out
This analog audio output is the summation of the receive audio of either or both transceiver
modules. It does not output sidetone. Normally this audio is provided for special applications
where a speaker rather than Headset is used. It can drive a 10K load with 2.0 Vrms. This output
is intended to drive a powered speaker. Use shielded wire.
6 - External Speaker Return
This pin provides the ground path for the external speaker output. Use shielded wire.
7 - PTT 1 Input
This input when grounded activates the transmitter for FM - 1 or FM - 2 (Depending on operating
mode and selected transceiver). Normally this is connected to the audio panel PTT output. If a
discreet microphone is being used (no audio panel) this pin should be tied to Mic 1 Input L.
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.
