FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
INSTALLATION MANUAL
Publication No. 150-049106 Page 43 of 56
Rev. F P-2000 Installation Manual
Nov 2007
3. Connector Pin Number and Descriptions
The following tables and pin descriptions are for the P-2000/C-2000/RT-2000 J101 (DB-25) and J102
(DB-15) connectors.
J101 Pin Numbers and Signal Names
Pin SIGNAL NAME
1 Headset 1 Out H
2 Headset 1 Out L
3 CAN Data H
4 CAN Data L
5 External Speaker Out
6 External Speaker Return
7 PTT 1 Input
8 Mic 1 Input H
9 Mic 1 Input L
10 Shield Ground
11 External On/OFF Control
12 Panel Lite Return
13 Headset 2 Out H
14 Headset 2 Out L
15 Reserved Spare #1
16 28 Vdc Panel Lite
17 5 V Panel Lite
18 Reserved Spare #2
19 28 Vdc Aircraft Power
20 28 Vdc Aircraft Return
21 PTT 2 Input
22 Reserved Spare #3
23 Mic 2 Input H
24 Mic 2 Input L
25 PB Out
Table 3-1 J101 Pin Numbers and Signal Names
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.
