FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
Installation Manual
Page 6 of 56 Publication No. 150-049106
P-2000 Installation Manual Rev. F
Nov 2007
CHARACTERISTICS DESCRIPTION
FCC Emission Designator
137 – 174 MHz Part 90, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D, 20K0F1E
380 – 520 MHz Part 90, 16K0F3E, 11K0F3E,8K10F1E, 8K0F1D, 20K0F1E
764 – 870 MHz Part 90, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D, 20K0F1E
Altitude 55,000 feet ASL (15,545 meters)
Temperature Range
Operation
-30°C to 60°C (-22°F to +140°F)
Storage
-55°C to 85°C (-67°F to +185°F)
Cooling Free air circulation
Weight
RT-2000 (Single Transceiver) 2.30 lbs. Max.
RT-2000 (Dual Transceiver) 2.90 lbs. Max.
Mounting Mounting Tray
Overall Dimensions
Height 3.0 inches max.
Width 5.75 inches max.
Length 7.49 inches max (without Mating Connectors)
Input Power Requirements
Normal Voltage Range 22.0 to 30.3 Vdc
Abnormal Voltage Range 20.5 to 32.2 Vdc
Emergency Operation Not Supported
RT-2000 (Single Transceiver)
Receive 0.75 Amp Nominal 1.2 Amp Max
Transmit 2.50 Amp Nominal 3.0 Amp Max.
RT-2000 (Dual Transceiver)
Receive 0.75 Amp Nominal 1.2 Amp Max
Transmit 3.50 Amp Nominal 4.0 Amp Max.
Frequency Band P-2000/RT-2000 Any combination of one or two bands listed below
137-174 MHz,
403-470 MHz, 380-470 MHz
450-520 MHz
806-870 MHz, 764-870 MHz
Data Bus CAN Serial with Wulfsberg Proprietary Protocol
Encryption Options AES/DES/DES-XL/DES-OFB/DVP/DVI
OTAR Options MDC1200 OTAR, P25 OTAR
Trunking Options Smartnet, Smartzone, P25
Receiver Specifications
Modes FM, P-25, P-25 Trunking, Motorola 3600 Baud Trunking
Sensitivity
Analog (12 dB SINAD) Better than .4 uV (-115 dBm)
Digital (5% BER) Better than .4 uV (-115 dBm)
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.
