FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
Installation Manual
Page 48 of 56 Publication No. 150-049106
P-2000 Installation Manual Rev. F
Nov 2007
These pins select which internal module receives the RS232 data being transferred on pins 1 and 2
of J102. The choices for these pins are listed in the table below:
Pin 3 Pin 4 Selection
N/C N/C CPU Board Processor Test Port
Ground N/C Display Board Processor Test Port
N/C Ground CPU Board Processor ISP Port
Ground Ground CPU Board RS232 Bus
5 - ISP Start Discrete
This pin is used only during ISP software loading during maintenance.
6 - Normalized Audio 1 Out H
This audio pin outputs audio from FM -1 at a constant level - i.e. it is not controlled by the volume
control. This output will produce 2.0Vrms into a 10K load.
7 – Reserved Spare #1
This pin reserved for future use.
8 – Normalized Audio 2 Out H
This audio pin outputs audio from FM -2 at a constant level - i.e. it is not controlled by the volume
control. This output will produce 2.0Vrms into a 10K load.
9 – Reserved Spare #2
This pin reserved for future use.
10 - Ground
Ground.
11 – General Input #1
Multi-purpose discreet input that can be configured based upon system operation
12 – General Input #2
Multi-purpose discreet input that can be configured based upon system operation
13 – General Output #1
Multi-purpose discreet output that can be configured based upon system operation.
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.
