68
6. Installation and Startup
6.1. Assembly / Installation
Vibrating motors can be installed in any installation position. They may only be
attached to machines with flat, oil, grease, and paint-free and rigid mounting
(machined) surfaces.
Surface quality:
Only screws of quality class ≥ 8.8 ISO 4014 (DIN 931) or ISO 4017 (DIN 933)
and nuts of quality class ≥ 8.8 ISO 4032 (DIN 934) may be used.
They must be secured against mechanical loosening (for example by Nord-Lock
washers, RIPP LOCK or Schnorr washers or similar).
The fastening must be checked for tightness after approx.
Two hours of operation and re-tightened if necessary.
Further checks should be carried out daily!
Improper attachment will lead to breakage off the feet of
the vibrating motor.
Tightening torques for fastening screws/-nuts:
Aluminium Stator cases: HV 0,1 HV 30, HV 55 & HV 85
M8
M12
M16
M20
M22
M24
30
Nm
90
Nm
150
Nm
280
Nm
370
Nm
450
Nm
GJS Stator cases: from size HV 40 onwards (except HV 55 & HV 85)
M16
M20
M22
M24
M27
M30
M36
210
Nm
400
Nm
550
Nm
700
Nm
1100
Nm
1350
Nm
2500
Nm
Always tighten the fastening screws crosswise.
For elongated holes (HV 0.4, HV 1, HV 2 and HV 6), ISO 7089 (DIN 125)
washers must also be used.
