78
7.2. Centrifugal Force Adjustment with Casted
Snap-in Unbalance Discs
With types HV 2/2-6, HV 2/4-6 and HV 2/4-9, the centrifugal force is adjusted in
stages by symmetrically turning the two outer unbalance disks (HV 2/2-6 and
2/4-9 only are only available as 50Hz versions).
The external imbalances are held in position by a cast grid.
The following centrifugal force settings are possible:
