13. Single Phase Use with
Capacitors 1~230V 50Hz AC
The motor must be switched to  230 V (see page 71)
Exception HV 0.4 the motor cannot be switched.
Use capacitors with a permissible voltage of 320 V:
Motor
Capacitor
HV 0,4/2 230V
2
HV 1/2
7
HV 2/2-4
12
HV 2/2-6
12
HV 6/2
30
HV 1/4
4
HV 2/4-4
10
The associated capacitor must not be mounted directly on the unbalance motor,
because the capacitor must be protected from vibration.
