The centrifugal force of the motor is reduced in the case of a 180 ° rotated
unbalance as follows:
2-poles, 3000 min
-1
50Hz, 3600 min
-1
60Hz
Number of discs
per motor
Number of rotated discs by 180° on each side of the motor shaft
0
1
2
3
4
5
6
7
8
9
HV 0,4/2
50Hz
8
100%
50%
-
-
-
-
-
-
-
-
60Hz
HV 0,4/2-1
50Hz
18
100%
77,8%
55,6%
33,3%
11,1%
-
-
-
-
-
60Hz
HV 1/2
50Hz
20
100%
90%
80%
70%
60%
50%
40%
30%
20%
60Hz
16
100%
-
HV 2/2-4
50Hz
16
100%
75%
50%
25%
-
-
-
-
-
-
60Hz
HV 6/2
50Hz
16
100%
75%
50%
25%
-
-
-
-
-
-
60Hz
12
100%
67%
33%
-
-
-
-
-
-
HV 6/2-8
50Hz
22
100%
82%
64%
45%
27%
9%
-
-
-
-
60Hz
16
100%
75%
50%
25%
HV 8
50Hz
12
100%
67%
33%
-
-
-
-
-
-
-
60Hz
8
100%
50%
-
-
-
-
-
-
-
-
HV 8/2-11
50HZ
14
100%
60Hz
10
100%
HV 12/2
50Hz
16
100%
75%
50%
25%
-
-
-
-
-
-
60Hz
12
100%
67%
33%
-
-
-
-
-
-
-
HV 15/2
50Hz
20
100%
71%
43%
14%
-
-
-
-
-
-
60Hz
14
100%
60%
20%
-
-
-
-
-
-
-
HV 15/2-20
50Hz
20
100%
80%
60%
40%
20%
-
-
-
-
-
60Hz
14
100%
71%
43%
14%
-
-
-
-
-
-
HV 15/2-25
50Hz
20
100%
86%
71%
57%
43%
29%
14%
-
-
-
60Hz
14
100%
80%
60%
40%
20%
-
-
-
-
-
HV 30/2
50Hz
28
100%
86%
71%
57%
43%
29%
14%
-
-
-
60Hz
20
100%
80%
60%
40%
20%
-
-
-
-
-
HV 55/2
50Hz
24
100%
83%
67%
50%
33%
17%
-
-
-
-
60Hz
16
100%
75%
50%
25%
-
-
-
-
-
-
4-poles, 1500 min
-1
50Hz, 1800 min
-1
60Hz
Number of discs
per motor
Number of rotated discs by 180° on each side of the motor shaft
0
1
2
3
4
5
6
7
8
9
HV 2/4-4
50Hz
16
100%
75%
50%
25%
-
-
-
-
-
-
60Hz
HV 6/4-11
50Hz
30
100%
87%
73%
60%
47%
33%
20%
7%
-
-
60Hz
22
100%
82%
64%
45%
27%
9%
-
-
-
-
HV 6/4-18
50Hz
46
100%
91%
83%
74%
65%
57%
48%
39%
30%
22%
60Hz
32
100%
88%
75%
63%
50%
38%
25%
13%
HV 12/4-18
50Hz
24
100%
83%
67%
50%
33%
17%
-
-
-
-
60Hz
16
100%
75%
50%
25%
-
-
-
-
-
-
HV 12/4-30
50Hz
40
100%
90%
80%
70%
60%
50%
40%
30%
20%
10%
60Hz
28
100%
86%
71%
57%
43%
29%
14%
-
-
-
HV 12/4-42
50Hz
30
100%
87%
73%
60%
47%
33%
20%
7%
-
-
60Hz
20
100%
80%
60%
40%
20%
-
-
-
-
-
6-poles, 1000 min
-1
50Hz, 1200 min
-1
60Hz
Number of discs
per motor
Number of rotated discs by 180° on each side of the motor shaft
0
1
2
3
4
5
6
7
8
9
HV 6/6
50Hz
16
100%
75%
50%
25%
-
-
-
-
-
-
60Hz
12
100%
67%
33%
-
-
-
-
-
-
-
HV 6/6-18
50Hz
46
100%
91%
83%
74%
65%
57%
48%
39%
30%
22%
60Hz
32
100%
88%
75%
63%
50%
38%
25%
13%
HV 12/6-42
50Hz
30
100%
87%
73%
60%
47%
33%
20%
7%
-
-
60Hz
20
100%
80%
60%
40%
20%
-
-
-
-
-
