Wylie Express - Accessory Components; Anti-Siphon Fill Kit Parts; Hose Reel Assembly Parts

27
Axle & Hub Parts for 500 Gallon Trailer
Axles & Hubs (tandem brake axles)
1
2
3
4
5
1
2
No. Part No. Description No. Part No. Description
1 40716 Surge Brake, 10”-2¼” LH 2F L-44610 Outer Race, 1.98” OD
40715 Surge Brake, 10”-2¼” RH 2G L-44649 Outer Bearing, 1.0625” ID
2 94655 Complete Brake Hub Ass’y. 2H 4753 Spindle Washer, 1”
94655-1 Brake hub w/ cups & studs 2J 4754-Q Spindle Nut, 1”-14
2B 4-12 Brake Flange 2K 4755 Cotter Pin, 1/8”x2”
2C 171255TB Grease Seal, single lip, 1.709” 2L RP-100 Rubber Plug, Accu-Lube Grease Cap
2D L-68149 Inner Bearing, 1.375” ID 3 4342-17 Spring, Double Eye, 1700#
2E L-68111 Inner Race, 2.362” OD 4 4102-A Tandem Hanger Kit
5 TS35705525655FBX 3,500# Surge Brake Axle wAccuLube hubs
Axle & Hub Parts for 1,025, 1,250 Gallon Trailer
No. Part No. Description No. Part No. Description
1 4704-L Electric Brake, 12”-2¼” LH 2F 14276 Outer Race, 2.717” OD
4704-R Electric Brake, 12”-2¼” RH 2G 14125A Outer Bearing, 1.25” ID
42029 Surge Brake, 12”-2¼” LH 2H 4753 Spindle Washer, 1”
42028 Surge Brake, 12”-2¼” RH 2J 4754 Spindle Nut, 1”-14
2 92865A Complete Brake Hub Ass’y. 2K 4755 Cotter Pin, 1/8”x2”
92865A-1 Brake hub w/ cups & studs 2L 1605 Grease Cap
2B 4-6T Brake Flange 3 4351-30 Slipper Spring 5 Leaf, 27”x2”
2C 22333VB Grease Seal, single lip, 2.25” 4 W120510 Equalizer Bar
2D 25580 Inner Bearing, 1.75” ID 5 TS70705525865FBC 7,000# Surge Brake Axle w/AccuLube hubs (1,025)
2E 25520 Inner Race, 3.625” OD TX70895730865EBC 7,000# Elec. Brake Axle w/AccuLube hubs (1,250)
“Express” Axles
1
2
3
4
5
5
