Unfold Propeller
After unfolding all the propellers, check whether the model of propeller, which could be seen between
clamp and blade, corresponds to the Arm Number. CW Propellers correspond to Arm No.1 & No. 3,
while CCW Propellers correspond to Arm No.2 & No.4.
Arm No.1Arm No.2
Arm No.3 Arm No.4
CW Propeller - Arm No.1/3 CCW Propeller - Arm No.2/4
NEVER swap the CW and CCW Propellers, as incorrect installation may cause ight accidents.
Warning
