Operation
3-18 975-0057-01-01
To connect the XPower Powerpack to an external battery
using the jump-start cables:
1. Connect the cables to the Jump-Start Cable Port on the
left side of the XPower Powerpack.
2. Connect the red positive (+) clip of the cables to the red
positive (+) terminal of the external battery.
3. Connect the black negative (–) clip of the cables to the
black negative (–) terminal of the external battery.
To disconnect the cables from an external battery and
from the XPower Powerpack:
1. To disconnect the XPower Powerpack from the external
battery when the external battery is discharged or no
longer needed, remove the red positive (+) clip, and then
remove the black negative (–) clip.
2. Remove the cables from the Jump-Start Cable Port.
WARNING: Acid spills
Use a sealed, non-spillable battery for indoor use.
Common auto and marine batteries are not suitable
for indoor use unless their fumes are vented
outdoors. Common auto and marine batteries
contain acid, which is hazardous if spilled. Wear
eye protection and protective clothing when
connecting the XPower Powerpack to an external
battery.
WARNING: Sparking and Explosion
Do not remove the cables from the Jump-Start
Cable Port when the positive and negative clamps
are connected to the terminals of the external
battery.
