Installing the Auto Gen Start
975-0082-01-01 2–21
Type 12
Type 12 is a three-wire GlowStop configuration recommended for “three-
wire” generators that don’t require a dedicated preheat signal, such as
Onan propane generators. In this configuration, the start signal is applied
for longer because the generator does its own preheat and cranking while
the start signal is applied.
The wiring diagram for a Type 12 configuration is the same as a three-
wire Type 2 configuration. See Figure 2-4.
Table 2-13
Type 12 relay and timing preset configurations
Relay 1 mode
GlowStop
Relay 3 mode
No function
Gen Run signal hold time
4 s
Preheat time
0 s
Preheat to crank delay
0 s
Crank time
30 s
Crank retry time
40 s
Shutdown bypass time
0 s
Start tries
3
