Installation
2–22 975-0082-01-01
Type 13
Type 13 is a three-wire PulseStop configuration that uses relay 3 to
provide the preheat signal for PowerTech’s Diesel generators. With this
generator type, there will be a delay between the generator turning off and
the Auto Gen Start recognizing that the generator is off.
The wiring diagram for a Type 13 configuration is the same as a Type 4
(see Figure 2-6).
Table 2-14
Type 13 relay and timing preset configurations
Relay 1 mode
PulseStop
Relay 3 mode
Preheat
Gen Run signal hold time
5 s
Preheat time
15 s
Preheat to crank delay
2 s
Crank time
15 s
Crank retry time
15 s
Shutdown bypass time
0 s
Start tries
3
