Planning the Installation
8
Planning the Installation
Supplied Parts
❐ Link 1000 control panel and 4 mounting screws
❐ 500 amp precision shunt
❐ 25 foot RJ11 phone cable
❐ Owner’s guide
Materials You Need to Supply
Refer to Figure 2 on page 12.
❐ Wire harness to connect the Link 1000 control panel to
the shunt and to the positive battery terminal. You can
use 18AWG, twisted pair, for this wiring. You can also
buy the harness from the dealer you bought the Link
1000 from or from West Marine.
Contact West Marine at:
• 1-800-BOATING (Canada and US)
• Fax: 1-831-761-4421 (Canada and US)
When ordering the harness, quote these part numbers:
• 84-2014-00: 25 foot (7.62m) 8-conductor twisted pair
wire
• 84-2015-00: 50 foot (15.24m) 8-conductor twisted pair
wire
❐ Appropriately sized copper cable and connectors to
connect the shunt to the battery and the negative bus for
DC loads
Consult a local cable supplier about cable size and
connector type. You may find it convenient to have the
cable supplier attach the connectors.
❐ 2, 2 amp fuses and fuse holders. (Three fuses and fuse
holders if you are monitoring a second battery.)
❐ 2 screws to mount the shunt
