Control Panel: Electrical Specifications
52
Control Panel: Electrical Specifications
Control Panel: Physical Specifications
DC Power supply voltage 8–40 VDC. (Not for use with 32 volt
systems.)
Power consumption For 12 volt systems:
• 90 mA (typical)
• 170 mA (full display brightness)
• 25 mA (sleep mode; only
BATTERY STATUS LEDS on.)
Values are approximately half on 24
volt systems.
Voltage measurement range 0.1–50 VDC
Voltage resolution 0.05 VDC
Voltage accuracy ±0.10 VDC at full scale
Current measurement range ±500 Amps DC
Current resolution • 0.1 amp DC (from ±0–±42.0
amps)
• 1 amp DC (from ±42–±500
amps)
Current accuracy • ±0.1 amp DC at full scale low
range
• ±1 amp DC at full scale high
range
Current shunt ±0.25% ratio: 50mV @ 500A
Amp hour range ±1,999Ah
Time remaining range 255 hours maximum
Width 4.725 in. (120 mm)
Height 2.975 in. (75.5 mm)
Depth 1.075 in. (27.3 mm)
Weight 4.6 oz. (2 g)
Front panel finish Water resistant, splash proof
