Xantrex Trace DR Series User Manual

35
2.0 INSTALLATION
©2000 Xantrex Technology Inc.
Series Stacking (continued)
Figure 29
Stacking Port and Battery Wiring with One Disconnect
(120 VAC/60 Hz models only)
Figure 30
Stacking Port and Battery Wiring with Two Disconnects
(120 VAC/60 Hz models only)
DC
Disconnect
Negative
Tie
Series Stacking
Cable (DRI)
975-0012-009
+
–
+
–
+
–
+
–
Positive
Tie
Inverter 1
(L1)
Inverter 2
(L2)
DC
Disconnect
Negative
Tie
Series Stacking
Cable (DRI)
975-0012-010
+
–
+
–
+
–
DC
Disconnect
+
–
Inverter 1
(L1)
Inverter 2
(L2)
