Preparing for Installation
2–7
Tools
To mount and connect Truecharge+ you need:
❐ a slot screwdriver with a maximum 3/16 in wide blade for the DC
terminals
❐ a No. 1 Phillips screwdriver for securing the AC wiring compartment
cover
❐ a wire stripper
❐ the manufacturer's recommended crimp tool for any crimp terminals
that are being used
Materials
You need the following material:
❐ 3 conductor No. 14 AWG AC cable
❐ Appropriately sized DC cables for each battery, with suitable
connectors at the battery end
❐ DC fuse and disconnect or circuit breaker for each battery bank
❐ Mounting hardware (#8 recommended), minimum 4.
❐ Other means to route and secure AC and DC wiring
