Electrical Specifications
A–3
Absorption voltage
Hot Warm Cold
Flooded 14.0 14.4 14.8 VDC
Gel 13.8 14.2 14.6 VDC
AGM 14.0 14.3 14.6 VDC
Float voltage at no load
Hot Warm Cold
Flooded 13.1 13.5 13.9 VDC
Gel 13.4 13.8 14.2 VDC
AGM 13.1 13.4 13.7 VDC
Equalize mode current Truecharge 20 +
5 ADC
Truecharge 40+
10 ADC
Equalize mode—maximum
output voltage
16.0 VDC
Fixed voltage mode—nominal
output voltage
13.5 ± 0.12 VDC
