975-0526-01-02 57
Specifications
Protection Features
Battery reverse polarity Protected by replaceable DC output
fuses
Over-voltage limits The Truecharge2 Battery Charger will
stop charging if the output voltage is
above
16.6 ±0.5 Vdc for 12 Vdc units,
33.2 ±0.1 Vdc for 24 Vdc units.
Output current limit
TC2012:
TC4012:
TC6012:
TC1024:
TC2024:
TC3024:
20 +10% A
40 +10% A
60 +10% A
10 +10% A
20 +10% A
30 +10% A
Over-temperature
(measured internally)
Shutdown at 65 ±5 °C (149 ±9 °F)
Restart at 60 ±5 °C (140 ±9 °F)
Battery over-temperature
protection
Charger shuts down if battery
temperature above 70 °C (158 °F) is
sensed by the battery temperature
sensor (BTS).
Battery under-temperature
protection
Charger shuts down if battery
temperature below –25 °C (–13 °F) is
sensed by the battery temperature
sensor (BTS).
Regulatory Approvals
Safety
North America
NRTL approved to CSA E60335-2-29, UL1236 including
the marine supplement, and UL1564.
ABYC E11 - Alternating Current and Direct Current
Electrical Systems on Boats, and
ABYC A31 - Battery Chargers and Inverters.
European Union
CE marked for the Low Voltage Directive 2006-95-EC,
(complying with EN60335-2-29 Battery Chargers).
EN 28846 - Small Craft Electrical Devices, Protection
against ignition of surrounding flammable gases.
Australia
Designed to IEC60335-2-29 including Australian
deviations.
EMC
North America
Class B according to FCC Part 15B and Industry Canada
ICES-003.
European
CE marked for the EMC Directive 2004-108-EC
(complying with EN55014-1, EN55014-2, EN61000-3-2,
and EN61000-3-3).
Protection Features
TC2 204060 Series BattChg Owners Guide.book Page 57 Friday, July 8, 2011 11:44 AM
