4-26 DocuTech 128/155/180 HighLight Color Operator Guide
Problem Solving
11. Ensure that area 18 is clear of all binder tape adhesive. If it is
not, clean the binder using the procedure, "Cleaning the
binder," in the "Routine maintenance" chapter.
12. Close the finisher doors.
13. Close the top cover.
Stitcher spool A fault
NOTE: Production publisher configuration only
Repeated jams in area 17 may be caused by the following
problems:
• Stitcher wire not feeding properly
• A kink in the stitcher wire
1. Open the finisher doors.
2. Lift the stitcher panel, which is located directly above the
stitcher spools.
NOTE: If the spool is empty, replace the stitcher spool A. Refer to
online help for details.
3. Ensure that there is wire on the spool.
4. Pull the green stitcher head release handle forward and up
until it latches into place, as shown in figure 4-23.
Figure 4-23 Stitcher head release handle
