3-50 DocuTech 128/155/180 HighLight Color Operator Guide
Routine maintenance
2. Ensure that the glue is removed from the grooves on the
binder platen surface, which align with the top and bottom
edges of the book.
Figure 3-48 Cleaning the binder platen
Cleaning the flappers
NOTE: Production publisher configuration only
Using the binder platen cleaner, clean the top and side surfaces of
the binder flappers until all the glue is removed.
