Xerox 128 - Cleaning the Q1107 Sensor

DocuTech 128/155/180 HighLight Color Operator Guide 3-37
Routine maintenance
Figure 3-33 Q1106 and Q1166 sensors
Cleaning the Q1107 sensor
NOTE: High volume printer configuration only
To access sensor Q1107, open the top cover of the high capacity
stacker.
To clean the sensor:
1. Brush or wipe the sensor windows lightly.
2. Remove any dust present in the area.
