Xerox 8254E / 8264E Color Wide Format Printer
User Guide
6-10
8254E only - Roll media replacement steps
Follow the procedure below to replace roll media.
1. If the printer is turned ON, confirm that no operation such as printing is in progress.
WARNING:
• Be careful to not trap your fingers when opening and closing the media cover.
2. Raise the media loading lever.
3. Use the flanges at both ends of the scroller to manually rewind the roll media.
No. Name
1 Media loading lever
No. Name
1 Roll media
2 Scroller
