Product Overview
Xerox 8254E / 8264E Color Wide Format Printer
User Guide
2-4
8254E Printer Front Section
No. Name Function
1 Media loading lever Used for fixing or releasing media.
•Lower the lever to fix the media.
• Raise the lever to release the media.
2 control panel Used to control operation condition settings and to view printer status and
various function settings.
3 Front cover Used for preventing the user from coming in contact with the driving
mechanism during the printer operation. Opened and closed when media is
set or jammed. It is normally closed.
4 Stand Used to support the printer.
5 Book holder Quick Start Guide, etc. can be stored here. Can be mounted on either leg of
stand.
6 Media guide Used for feeding media smoothly when the media is set or printed.
The heater to dry the ink is installed under the guide.
7 Media cut groove Used to cut media straight.
To Next Page
