Xerox 8254E / 8264E Color Wide Format Printer
User Guide
6-12
6. Remove the roll media from the scroller.
7. To load another roll media, refer to the following.
Notes:
• For loading roll media, refer to Loading Roll Media.
• For storing roll media not in use, refer to Precautions for Storing Media.
8. When you have no need to set roll media, attach the movable flange to the scroller and store the
scroller in the printer’s scroller receivers.
The roll media replacement procedure for the 8254E is complete.
No. Name
1 Roll media
2 Scroller
No. Name
1 Movable flange
2 Scroller

Xerox 8254E Specifications

General

Brand	Xerox
Model	8254E
Category	Printer
Language	English
