Preparing For A Job
Xerox 8254E / 8264E Color Wide Format Printer
User Guide
3-14
5. Tighten the fixing lever on the roll media holder (Left) by ratcheting the lever clockwise until the roll
media holder is tightened and can’t be moved.
6. Mount the roll media onto the core of the roll media holder (Left). Make sure the media’s
cardboard tube is all the way onto the core so that it is flat against the inner part of the holder’s
flange.
No. Name
1 Roll media holder (Left)
2 Fixing lever
No. Name
1 Roll media holder (Left)
2 Roll media
