Preparing For A Job
Xerox 8254E / 8264E Color Wide Format Printer
User Guide
3-16
10. Engage the damper drive switching plates and their locking brackets on the end of each roll media
holder to increase tension on the media roll to avoid slack and "No media found" errors.
No. Name
1 Roll media holder (Left)
2 Roll media holder (Right)
3 Roll media
4 Fixing lever
