Preparing For A Job
Xerox 8254E / 8264E Color Wide Format Printer
User Guide
3-24
7. If the edge of the roll media is set less than 5mm from the edge of the pressurizing roller, follow the
procedure below to adjust the position of the roll media.
a. Loosen the fixing levers of the right and left roll media holders, and move the roll media to the left or
right.
b. After moving the roll media, fix it in place by re-tightening both fixing levers.
Note:
• Fix the roll media holders by pressing the holders to the printer.
No. Name
1 Roll media holder (Left)
2 Roll media holder (Right)
3 Roll media
4 Fixing lever
To Next Page
