XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction 58
Appendices
Appendix 1 - Key Features of the XES
Synergix 8825/8830/8850 Printer/Digital
Solution
XES Synergix 8825/8830/8850 Printer
• High quality, mid-volume printing.
• Full size media range: outputs from 11” to 36” (279 mm to 914 mm) wide
bond, film or vellum (tracing paper).
• 400 dpi, LED print engine delivering single pixel lines and 128 gray scales
(8825/8830) or 256 gray scales (8850).
• 8830: throughput at 4 ips, and 7 D(A1) size prints per minute
8825: throughput at 2 ips, and 4 D(A1) size prints per minute.
8850: throughput at 4.5 ips, and 10 D (A1) size prints per minute
• Hours of unattended operation with one to three media drawers. Media
sizes can be mixed. Users can mix ISO, ANSI and ARCH media size
standards, if necessary.
• Simple operator control panel with menus to assist in printer setup.
• Optional folder with programs selectable using the WebPMT.
• Optionally available Xerox Stacker 1000.
• Job Accounting and Scan-to-Net are standard features for the XES
Synergix 8830 and 8850 Digital Solutions. The XES Synergix 8825
printer can be upgraded with these optional features, as well as with the
PostScript option, using feature keys downloaded from the Internet
(www.xes.com/keys). Effective with Firmware Release 7.5, a new Color
Enablement feature key is available enabling Scanning-to-Net in color in
TIFF and JPEG formats. The printing of JPEG files is also enabled in
Firmware Release 7.5.
AccXES Controller
• N5T/CNG (8830/8850) or EV4 (8825) Controller, with or without the
PostScript option.
• Plug-and-play performance in standalone or networked configurations
with multiple ports: RS-232C Serial port; Bi-directional, IEEE P1284
Parallel port; and 10/100 T/TX Ethernet port for TCP/IP communication.
Support for EtherTalk, NetBEUI, and Novell is provided by an external
Ethernet Adaptor that plugs into the parallel port. VPI and SCSI ports are
standard on the N5T/CNG and optional on EV4.
• Automatic recognition and rasterization of HP-GL, HP-GL/2, HP-RTL,
CGM (level 1 with ATA ext.), C4, FileNET, Versatec Data Standards
(VRF, ordered vector, blocked raster, compacted raster), VCGL,
CalComp 906/907/957/PCI, TIFF 6.0, NIRS, CALS 1 & 2, JPEG, and
optional PostScript 3 with PDF.
• Printing from UNIX environments using lpr/lpd.
• Print collation from Windows applications that support collation (i.e.,
PowerPoint or Word).
• Collated sets of up to 12 drawings with standard (64 MB) RAM
configuration (depending on OS and application support features).
• Long plot printing up to 80 feet in length. Up to 100 feet of scanner-
supported copying.
• Easy firmware upgrades from individual workstations, using the Web
PMT.
• IEEE 1394 interface supporting the Synergix Scan System.
