Xerox DocuMate 252 User Manual

DocuMate 252 Scanner User’s Guide 111
Maintenance
Clearing Paper Jams
If your scanner stops scanning due to a paper jam in the Automatic
Document Feeder, a warning dialog box opens after a few
moments.
To clear a paper jam:
1. Press the ADF cover release on the top-left of the scanner
body to open the Automatic Document Feeder cover.
2. Remove the jammed paper and close the cover.
To reduce the number of paper jams, smooth and straighten the
paper before scanning and adjust the guides to the paper size.

Xerox DocuMate 252 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	48 bit
Maximum scan size	215 x 355 mm
Optical scanning resolution	600 x 1200 DPI
Scanner type	Sheet-fed scanner
Sensor type	CCD
Dimensions (WxDxH)	330 x 310 x 150 mm
Minimum system requirements	- Pentium II - Windows 2000/ME/XP - 128MB of RAM - 200MB hard disk space - CD-ROM - USB
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	3900 g
