Xerox
®
DocuMate
®
4760
User’s Guide
190
7. Locate the white tab that locks the feed roller module in the scanner. Using a flathead screw driver, carefully
wedge the flat head of the screw driver between the white tab and the roller housing.
8. Gently push the white tab away from the roller housing and rotate the tab up to unlock the roller.
9. Carefully angle the roller up and out of the scanner.
10. Discard the roller, it cannot be repaired or reused.
11. Before installing the new roller, clean any dust that may have gotten on it during shipping.
