5-5
EXPLODED VIEWS AND PARTS LIST
Service Manual
< Frame Assembly Parts List >
SA. : Service Available
O: Service available X: Service not available
NO DESCRIPTION SEC CODE Q’TY SA REMARK
0 ELA UNIT-FRAME ASSY JC96-02732A 1 X
1 FRAME-Base JC61-00579A 1 X
2 GUIDE-TR JC61-00607A 1 X
3 PLATE-SAW JC61-00604A 1 X
4 GUIDE-TR RIB JC61-00594A 1 X
5 GEAR-EXIT F/DOWN JC66-00038A 1 X
6 MEC-BEARING,EXIT JC75-10529A 2 X
7 ROLLER-EXIT_F/DOWN JC66-00378A 1 X
8 SPRING-EXIT_F/DOWN 6107-001163 1 X
9 PMO-GEAR_EXIT_DRV16 JC72-00143A 2 X
10 HOLDER-EXIT_F/DOWN JC61-00582A 4 X
11 PMO-ROLLER_EXIT,MAIN JC72-41081A 4 X
12 PMO-ROLLER_EXIT,FR JC72-41082A 4 X
13 MEC-TERMINAL JC75-00049A 4 O
14 IPR-TERMINAL CON JC70-00312A 3 X
15 IPR-TERMINAL CR JC70-00313A 1 X
16 HOUSING-TERMINAL JC61-00592A 1 X
17 PMO-LOCKER CST JC72-00983A 1 X
18 PMO-ACTUATOR CVR OPEN JC72-00974A 1 O
19 PMO-PLATE GUIDE DEVE_R JC72-00985A 1 X
20 SPRING-GUIDE DEVE JC61-00038A 2 X
21 IPR-GROUND_ROLLER IDLE JC70-00315A 1 X
22 PMO-PLATE GUIDE DEVE_L JC72-00984A 1 X
23 PMO-ACTUATOR FEED JC72-00976A 1 O
24 PMO-ACTUATOR EMPTY JC72-00975A 1 O
25 PMO-ACTUATOR MANUAL JC72-00977A 1 O
26 IPR-GROUND EARTH TR JC70-00309A 1 X
27 SPRING-TR_R 6107-001162 1 X
28 ROLLER-FEED ROLLER1 JC66-00526A 1 X
29 PMO-BUSHING TX JC72-00382A 5 X
30 ROLLER-FEED JC66-00598A 1 O
31 SPRING-ACT,MANUAL 6107-001165 1 X
32 IPR-EARTH TRANSFER JC70-00307A 1 X
33 HOLDER-PTL JC61-00583A 1 O
34 LENS-PTL JC67-00027A 1 O
35 BUSH-TR_L JC61-00588A 1 X
36 SPRING-TR_L JC61-00047A 1 X
37 SPRING-ACT_FEED 6107-001164 1 X
38 PMO-BUSHING TR_L JC72-00102A 1 X
39 IPR-GROUND FUSER JC70-00310A 1 X
