5-6
EXPLODED VIEWS AND PARTS LIST
Service Manual
< Frame Assembly Parts List Cont. >
SA. : Service Available
O: Service available X: Service not available
NO DESCRIPTION SEC CODE Q’TY SA REMARK
40 SHAFT-FEED IDLE JC66-00527A 1 X
41 BUSH-FEED IDLE JC61-00585A 1 X
42 SPRING-FEED IDLE JC61-70958A 1 X
43 IPR-P_GROUND_DRIVE2 JC70-00335A 1 X
44 SPRING-CAM PICK-UP 6107-001170 1 X
45 CAM-PICK_UP JC66-00377A 1 X
46 IPR-GROUND DRIVE JC70-00308A 1 X
47 SOLENOID-HB (PICK-UP) JC33-00009A 1 O
48 SOLENOID-HB (MANUAL) JC33-00010A 1 O
49 TBD TBD 1 X
49-1 PMO-GEAR PICK_UP B JC72-00980A 1 X
49-2 PMO-GEAR PICK_UP A JC72-00979A 1 X
49-3 SPRING-PICK_UP GEAR 6107-001167 1 X
50 BRACKET-FEED JC61-00602A 1 X
51 IPR-GROUND TR JC70-00311A 1 X
52 SHAPT-FEED JC66-00398A 1 X
53 RING-CS 6044-000001 3 X
54 GEAR-FEED 2 JC66-00394A 1 X
55 GEAR-IDLE 23 JC66-00396A 1 X
56 GUIDE-PAPER JC61-00718A 1 X
57 RMO-RUBBER_FOOT JC73-00027A 2 X
58 PICK_UP ASS’Y TBD 1 O
58-1 BUSH-PICK_UP_L JC61-00586A 1 X
58-2 SHAFT-PICK_UP JC66-00399A 1 X
58-3 STOPPER-PICK_UP JC61-00593A 2 X
58-4 PMO-IDLE PICK_UP JC72-00982A 2 X
58-5 SPONGE-ROILLER PICK UP JC72-01231A 1 X
58-6 BUSH-PICK_UP_R JC61-00587A 1 X
58-7 HOUSING-PICK_UP JC61-00591A 1 X
59 CLUTCH ASS’Y(FEED ASS’Y) TBD 1 O
59-1 GEAR-FEED 1 JC66-00393A 1 X
59-2 PMO-COLLAR_SPRING JC72-00978A 1 X
59-3 SPRING-CLUTCH 6107-001164 1 X
59-4 PMO-HUB CLUTCH JC72-00981A 1 X
60 FUSER TBD 1 O
