Phaser 6700 Printer Service Manual Xerox Internal Use Only 9-53
Parts List 11.1 Electrical (1/2)
Item Description Part Number
1 Harness Assy TN CRUM (J11-J204,J205,206,J207) 962K73600
2 Harness Assy LV PWR (J23-J305) (LVPS Power Harness) 962K73650
3 Harness Assy ESS PWR (J306-J404) 962K73700
4 Harness Assy Video (J152-J328) 962K73850
5 Harness Assy REGI (J10-P101 ,P102, P103, P105,
P110)
962K74380
6 - -
7 Exit Harness (J20-P115,P116,J212,J224,J225) 962K74461
8 Harness Assy FIN (J22-P121) 962K74481
9 Harness Assy LVPS (J24-J308) (LVPS Harness) 962K74490
10 Harness Assy ESS (J2-J802) 962K73640
