Xerox PrimeLink B9125

1. On the front-edge guide, loosen the four screws.
Important: Before you make any adjustments, loosen both sides of the front-edge guides. If you adjust
the guides forcibly, the guides can become misaligned, then a service call is required.
2. Load the paper.
3. Adjust the front-edge guides on the XLS Bypass tray and the rear-edge guides on the XLS Feeder so that the
guides are as parallel to the printer as possible.
4. Run the Auto Alignment Adjustment procedure. Refer to the Xerox
®
PrimeLink
®
B9100/B9110/B9125/B9136
Copier/Printer System Administrator Guide.
Note: Only a system administrator can perform the Auto Alignment Adjustment procedure.
If the result of the auto alignment is not satisfactory, continue to the next step.
5. Loosen the four screws on the front-edge guide.
286
Xerox
®
PrimeLink
®
B9100/B9110/B9125/B9136 Copier/Printer User Guide
Tray 5 (Bypass)
