Xerox VersaLink C500 User Manual

PPrriinntteerr iiss MMaakkiinngg UUnnuussuuaall NNooiisseess
Probable Causes Solutions
There is an obstruction or debris inside the printer. Power off the printer, then remove the
obstruction or debris. If you cannot remove the
obstruction, contact your Xerox representative.
PPaappeerr TTrraayy WWiillll NNoott CClloossee
Probable Causes Solutions
The paper tray does not fully close.
• If the tray is extended for legal-size paper, the
tray protrudes when it is inserted into the printer.
For more information, refer to Configuring Tray 1
and Trays 2–5 for the Paper Length.
• Some debris or an object is blocking the tray.
• The tray is blocked by the table or shelf on which
it is located.
• If the paper lift plate at the back of the tray is not
locked down, replace the tray.
CCoonnddeennssaattiioonn HHaass FFoorrmmeedd IInnssiiddee tthhee PPrriinntteerr
Moisture can condense in the printer when room humidity exceeds 85% or when a cold printer is
located in a warm room. Condensation can form in a printer after it has been sitting in a cold room
that is heated quickly.
Probable Causes Solutions
The printer has been sitting in a cold
room.
Allow the printer to operate for several hours at room
temperature.
The relative humidity of the room is too
high.
• Reduce the humidity in the room.
• Move the printer to a location where the temperature and
relative humidity are within the operating specifications. For
more information, refer to Environmental Specifications.
152
Xerox
®
VersaLink
®
C500 Color Printer
User Guide
Troubleshooting

Xerox VersaLink C500 Specifications

General

Color	Yes
N-up printing	2, 4, 6, 8, 9, 16
Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	11 s
Time to first page (black, normal)	5 s
Time to first page (color, normal)	5.3 s
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	43 ppm
Duplex print speed (black, normal quality, A4/US Letter)	42 ppm
Display	LCD
Control type	Touch
Certification	CE
Product color	Black, Blue, White
Display diagonal	5 \
Market positioning	Business
Cables included	AC
Processor cores	2
Noise level (idle)	33.6 dB
Sound power level (standby)	4.9 dB
Sound power level (printing)	7.17 dB
Sound pressure level (printing)	56.2 dB
Standard interfaces	Ethernet, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivity	Wireless LAN
Sustainability certificates	ENERGY STAR
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service, Xerox PrintBack
Supported network protocols (IPv4)	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD
PCL fonts	83
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	Vietnam
Maximum duty cycle	120000 pages per month
Recommended duty cycle	0 - 10000 pages per month
Number of PostScript fonts	136
Number of print cartridges	4
Page description languages	PostScript 3
Average cartridge yield (CMY)	2400 pages
Average cartridge yield (black)	5000 pages
Maximum cartridge yield (black)	40000 pages
Current rating	8 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	74 W
Power consumption (printing)	730 W
Power consumption (PowerSave)	0.9 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Linux operating systems supported	Fedora 25, RedHat EL Linux, openSUSE 13.2
Other operating systems supported	HP-UX 11.31, IBM iSeries, Solaris 11
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	500 sheets
Maximum input capacity	3250 sheets
Paper tray 1 input capacity	550 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	150 sheets
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Legal
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Preprinted forms, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 80 lbs
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	465.5 mm
Width	427.4 mm
Height	443.4 mm
Package weight	Weight of the packaged product in gram.
