SSeettttiinngg DDeeffaauulltt PPrriinnttiinngg OOppttiioonnss ffoorr WWiinnddoowwss
When you print from any software application, the printer uses the print job settings specified in the
Printing Preferences window. You can specify your most common printing options and save them so
that you do not have to change the settings every time you print.
For example, if you want to print on both sides of the paper for most jobs, specify 2-sided printing in
Printing Preferences.
1. Navigate to the list of printers on your computer:
For Windows Server 2008 and later, click StartSettingsPrinters.
For Windows 7, click StartDevices and Printers.
For Windows 8.1 and Windows 10, right-click the Start iconControl PanelDevices and
Printers.
Note: If you are using a custom Start menu application, it can change the navigation path
to your list of printers.
2. In the list of printers, right-click the icon for your printer, then click Printing preferences.
3. In the Printing Preferenceswindow, click a tab, then select the options. To save the settings, click
OK.
Note: For more information about Windows print driver options, click the Helpbutton (?) in the
Printing Preferenceswindow.
SSeelleeccttiinngg PPrriinnttiinngg DDeeffaauullttss iinn WWiinnddoowwss ffoorr aa SShhaarreedd NNeettwwoorrkk
PPrriinntteerr
1. Navigate to the list of printers on your computer:
For Windows Server 2008 and later, click StartSettingsPrinters.
For Windows 7, click StartDevices and Printers.
For Windows 8.1 and Windows 10, right-click the Start iconControl PanelDevices and
Printers.
Note: If you are using a custom Start menu application, it can change the navigation path
to your list of printers.
2. In the list of printers, right-click the icon for your printer, then select Printer properties.
3. In the printer Properties dialog box, click the Advanced tab.
4. On the Advanced tab, click Printing Defaults.
5. Make your selections on the Print Driver tabs as needed, then click Apply.
6. To save the settings, click OK.
SSaavviinngg aa SSeett ooff CCoommmmoonnllyy UUsseedd PPrriinnttiinngg OOppttiioonnss ffoorr WWiinnddoowwss
You can define and save a set of options, so that you can apply them to future print jobs. In Xerox
®
App Gallery, you can save an app as default, so you can have app-by-app default settings for printing.
To save a set of printing options:
1. With the document open in your application, click FilePrint.
2. To open the Printing Preferences window, select your printer, then click Properties or Preferences.
3. In the Printing Properties window, click the tabs, then select the required settings.
78
Xerox
®
VersaLink
®
C500 Color Printer
User Guide
Printing

Other manuals for Xerox VersaLink C500

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox VersaLink C500 and is the answer not in the manual?

Xerox VersaLink C500 Specifications

General IconGeneral
ColorYes
N-up printing2, 4, 6, 8, 9, 16
Print technologyLaser
Maximum resolution1200 x 2400 DPI
Duplex printing modeAuto
Warm-up time (from sleep mode)11 s
Time to first page (black, normal)5 s
Time to first page (color, normal)5.3 s
Print margins (top, bottom, right, left)4 mm
Print speed (black, normal quality, A4/US Letter)43 ppm
Duplex print speed (black, normal quality, A4/US Letter)42 ppm
DisplayLCD
Control typeTouch
CertificationCE
Product colorBlack, Blue, White
Display diagonal5 \
Market positioningBusiness
Cables includedAC
Processor cores2
Noise level (idle)33.6 dB
Sound power level (standby)4.9 dB
Sound power level (printing)7.17 dB
Sound pressure level (printing)56.2 dB
Standard interfacesEthernet, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivityWireless LAN
Sustainability certificatesENERGY STAR
Wi-FiNo
Cabling technology10/100/1000Base-T(X)
Security algorithms256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print, Mopria Print Service, Xerox PrintBack
Supported network protocols (IPv4)TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD
PCL fonts83
Printer fontsPCL, PostScript
Printing colorsBlack, Cyan, Magenta, Yellow
Country of originVietnam
Maximum duty cycle120000 pages per month
Recommended duty cycle0 - 10000 pages per month
Number of PostScript fonts136
Number of print cartridges4
Page description languagesPostScript 3
Average cartridge yield (CMY)2400 pages
Average cartridge yield (black)5000 pages
Maximum cartridge yield (black)40000 pages
Current rating8 A
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)74 W
Power consumption (printing)730 W
Power consumption (PowerSave)0.9 W
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Linux operating systems supportedFedora 25, RedHat EL Linux, openSUSE 13.2
Other operating systems supportedHP-UX 11.31, IBM iSeries, Solaris 11
Server operating systems supportedWindows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Paper input typePaper tray
Total input capacity700 sheets
Total output capacity500 sheets
Maximum input capacity3250 sheets
Paper tray 1 input capacity550 sheets
Total number of input trays1
Multi-Purpose tray input capacity150 sheets
Storage temperature (T-T)0 - 35 °C
Operating temperature (T-T)10 - 32 °C
Operating relative humidity (H-H)10 - 85 %
Custom media width76 - 216 mm
Maximum print size216 x 356 mm
Custom media length127 - 356 mm
Paper tray media typesBond paper, Card stock, Envelopes, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight60 - 220 g/m²
Non-ISO print media sizesLegal
Multi-purpose tray media typesBond paper, Envelopes, Labels, Letterhead, Plain paper, Preprinted forms, Recycled paper
Maximum ISO A-series paper sizeA4
Paper tray media weight (imperial)16 - 80 lbs
Harmonized System (HS) code84433210
Weight and Dimensions IconWeight and Dimensions
Depth465.5 mm
Width427.4 mm
Height443.4 mm
Package weightWeight of the packaged product in gram.
