Page #106 background imageLoading...
Page #106 background image
2. Touch Copy.
3. Touch Booklet Creation.
If you adjusted the Reduce/Enlarge setting, a message appears that confirms that Reduce/
Enlarge changed to Auto%.
If you set Paper Supply to Auto Select, a message appears that confirms that the paper
supply changed to Tray 1.
4. Touch the Booklet Creation toggle button.
5. Touch Original Document, then select the option that matches your original documents.
1-Sided Original: This option scans only one side of the original image and produces 1-sided
output files.
2-Sided Original: This option scans both sides of the original image.
2-Sided, Rotate Side 2: This option scans both sides of the original image, rotating the
second side.
6. If a cover sheet is required, touch the Cover toggle button, then adjust Paper Supply and Print
On Cover as needed.
7. If your printer has a finisher installed, select a staple or fold option.
8. To increase or reduce the amount of white space in the margin between the two pages, touch
Gutter Margin, then touch the Plus icon (+) or the Minus icon (-).
9. To print booklets containing an odd number of pages, touch Odd Page Management. To specify
the location of extra blank pages, touch Blank Page Front or Blank Page Back, as needed.
10. To set the number of sheets in the booklet, touch the Sheets per Signature toggle button. To
adjust the number of sheets, touch Plus icon (+) or Minus icon (-), as needed.
11. Touch OK.
Adding a Front Cover
You can print the first page of your copy job on different paper, such as colored or heavyweight
paper. The printer selects the special paper from a different tray. The cover can be blank or printed.
Note: This feature is only available if a hard drive is installed.
To add a front cover to your copy job:
1. At the printer control panel, press the Home button.
2. Touch Copy.
3. Touch Front Cover.
4. Touch the Front Cover toggle button.
Note: If Paper Supply is set to Auto Select, a notification appears confirming that the
Paper Supply has been changed to Tray 1.
106

Table of Contents

Other manuals for Xerox VersaLink C7120

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox VersaLink C7120 and is the answer not in the manual?

Xerox VersaLink C7120 Specifications

General IconGeneral
ColorYes
N-up printing2, 4, 6, 8, 9, 16
Duplex printing-
Print technologyLaser
Maximum resolution1200 x 2400 DPI
Time to first page (black, normal)6.9 s
Time to first page (color, normal)8.8 s
Print speed (black, normal quality, A3)11 ppm
Print margins (top, bottom, right, left)4 mm
Print speed (black, normal quality, A4/US Letter)20 ppm
PCL fonts83
Printer fontsPCL, PostScript
Printing colorsBlack, Cyan, Magenta, Yellow
Duplex functionsCopy, Print, Scan
Maximum duty cycle87000 pages per month
Recommended duty cycle0 - 5500 pages per month
Number of PostScript fonts136
Number of print cartridges4
Page description languagesHP-GL, JPEG, PCL 5e, PCL 6, PDF, PostScript 3, TIFF
DisplayLCD
Control typeTouch
Product colorBlue, White
Display diagonal7 \
Market positioningBusiness
Internal memory4096 MB
Processor cores2
Processor frequency1050 MHz
Sound power level (standby)4.1 dB
Sound power level (printing)6.9 dB
HDD capacity320 GB
Browser supportedMicrosoft Internet Explorer, Microsoft Edge, Mozilla Firefox, Apple Safari, Google Chrome
Languages supportMulti
FaxingNo
Cabling technology10/100/1000Base-T(X)
Security algorithms256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Mopria Print Service
Supported network protocols (IPv4)TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP Bonjour /AirPrint
AC input voltage220 - 240 V
AC input frequency50 Hz
Power consumption (sleep)0.4 W
Power consumption (standby)94 W
Storage temperature (T-T)0 - 35 °C
Operating temperature (T-T)10 - 32 °C
Operating relative humidity (H-H)10 - 85 %
Optional connectivityWireless LAN
Scan toE-mail, Network folder, SMB
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Maximum scan area297 x 431.8 mm
Output color depth24 bit
Output grayscale depth8 bit
Image formats supportedJPEG, TIFF
Document formats supportedPDF
Optical scanning resolution600 x 600 DPI
Mac operating systems supportedMac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Other operating systems supportedHP-UX 11, HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 11 SPARC, Solaris 8, Solaris 9, Solaris 9 SPARC
Server operating systems supportedWindows Server 2008, Windows Server 2008 R2
Windows operating systems supportedWindows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Copier resize25 - 400 %
Maximum number of copies999 copies
Time to first copy (black, normal)5.7 s
Time to first copy (color, normal)8.1 s
Copy speed (black, normal quality, A4)20 cpm
Custom media width88.9 - 297 mm
Custom media length98.4 - 431.8 mm
Paper tray media typesBond paper, Card stock, Heavy printing media, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight60 - 256 g/m²
ISO A-series sizes (A0...A9)A3, A4
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA3
Auto Document Feeder (ADF) media weight38 - 128 g/m²
Total input capacity620 sheets
Total output capacity250 sheets
Paper tray 1 input capacity520 sheets
Multi-Purpose tray input capacity100 sheets
Included cartridge capacity (CMY)9800 pages
Included cartridge capacity (black)16100 pages
Weight and Dimensions IconWeight and Dimensions
Depth670.8 mm
Width590 mm
Height766.5 mm
Weight62500 g
