Scanner Options, Maintenance and Troubleshooting Xerox
®
W130 / W110 Scanner
User Guide 6-9
WARNING: Keep all replaceable parts out of the reach of children. These parts are
small and pose a choking hazard.
Turn off the scanner power then unplug the power cord from the scanner. Pull the cover release
handle and open the scanner.
When you are done replacing the rollers, close the scanner carefully pressing down on both sides
of the cover until it locks in place. Do not slam down the cover.
Replacing the Pick Up Rollers
1. Pull down the paper feed roller cover and pull it towards you to access the rollers.
