6.3 Physical Specifications
Table 6-3 Physical specifications
Category Description
Dimensions (H x W x
D)
● 3.5" drive chassis: 43 mm x 447 mm x 798 mm (1.69
in. x 17.6 in. x 31.42 in.)
● 2.5" drive chassis: 43 mm x 447 mm x 798 mm (1.69
in. x 17.6 in. x 31.42 in.)
Figure 6-1 Physical dimensions (example: 2.5" drive
chassis)
NOTE
● See Figure 6-1 for methods of measuring physical
dimensions of the chassis.
● The measuring method for chassis with 3.5" drives and that
for chassis with 2.5" drives are the same. The chassis with
3.5" drives is used as an example.
