Sensor Description Component
DIMMN DIMM status DIMM N
N indicates the DIMM slot
number.
RTC Battery RTC battery status. An
alarm is generated when
the voltage is lower than
1 V.
RTC battery on the
mainboard
Power Button Power button pressed Mainboard and power
button
Watchdog2 Watchdog Mainboard
Mngmnt Health Management subsystem
health status
Management module
UID Button UID button status Mainboard
PwrOk Sig. Drop Voltage dip status Mainboard
PwrOn TimeOut Power-on timeout Mainboard
PwrCap Status Power capping status Mainboard
HDD Backplane Entity presence Drive backplane
HDD BP Status Drive backplane health
status
Drive backplane
HDD BP$ Temp Drive backplane
temperature
Drive backplane
RiserN Card Entity presence Riser card N
N indicates the riser card
slot number. The value is
1 or 2.
RiserN 12V 12 V voltage supplied by
the mainboard to the riser
card
Mainboard
N indicates the riser card
slot number. The value is
1 or 2.
Riser$ Temp Riser card temperature Riser card
SAS Cable Entity presence SAS cable
LCD Status LCD health status LCD
LCD Presence LCD presence LCD
DISK$ Drive status Drive
RAID Presence RAID controller card
presence
RAID controller card
FusionServer 1288H V7 Server
Technical White Paper A Appendix
Issue 02 (2023-05-25) Copyright © xFusion Digital Technologies Co., Ltd. 87
