Appendix B. - Technical Specifications
Frequency band FM65-108MHz; AM108-136MHz(Rx); 350-390MHz(Rx);
136-174MHz (Rx/Tx); 220-260MHz (Rx/Tx); 400-520MHz (Rx/Tx);
Memory channels 999
Power supply batteria Li-Ion da 7.4V/ 3000 mAh
Operating temperature -10°C to + 45°C
Working mode monoband/dualband
Modulation F3E(FM)
Max. frequency deviation ≤ ±5KHz
Spurious radiation < -60dB
Frequency stability ±2.5 ppm
Rx sensitivity < 0.2uV
Audio output power ≥ 500mW
Dimensions 64x121x35mm (LxAxP)
Weight 240g
Specifications are subject to change without notice.
WARNING. Direct plug-in ac/dc power supply must be used for disconnecting the transceiver from the mains; the
desktop charger must be positioned close to the unit and easily accessible.
