2.4 How to Charge
a. Plug the AC adaptor into the AC outlet, and then plug the cable of the AC adaptor into the DC jack located on the back of the charger. The
i
ndicator light blinks orange and is then ready to charge a battery.
b. Plug the battery or the radio into the charger. Make sure the battery terminals are good in contact with charging terminals. The indicator light turns
to red--- charging begins.
c. It takes approximately 2-5 hours to fully charge the battery. When the lamp lights green, the charging is completed. Remove the battery or the radio
unit with its battery from socket.
When charging a radio (with battery) the indicating lamp will not turn into green to show the fully charged status if the radio is powered on. Only
when the radio is switched off will the lamp indicate normal operation. The radio consumes energy when it is power-on, and the charger
cannot detect the correct battery voltage when the battery has been fully charged. So the charger will charge the battery in constant voltage
mode and fail to indicate correctly when the battery has been fully charged.
2.5 LED Indicator
STATUS LED
No Battery Green and red alternately flashing
Charge Normally Red
Fully Charged Green
Trouble Red blinks fast for a long time
NOTE
：
Trouble means battery too warm, battery short-circuited or charger short-circuited.
2.6 How to Store the Battery
a. If the battery needs to be stored, keep it in status of 80% discharged.
b. It should be kept in low temperature and dry environment.
c. Keep it away from hot places and direct sunlight.
» Do not short circuit the battery terminals.
» Never attempt to remove the casing from the battery pack.
» Never store the battery in unsafe surroundings, as a short may cause an explosion.
» Do not put the battery in a hot environment or throw it into a fire, as it may cause an explosion.
Note: This radio supports two charging methods - Type-C USB charging and desktop charging (desktop charger not included).
