Xicom XT-50 - C-Band Performance Specifications

XT-50, XT-80, and XT-100 Amplifiers General Description 1-3
Table 1-2 C-Band Performance Specifications
Parameter XT-50C Specifications XT-100C Specifications
FREQUENCY RANGE 5.850 GHz to 6.425 GHz 5.850 GHz to 6.425 GHz
OUTPUT POWER TWT
@ Amplifier Flange
55 Watts
50 Watts
170 Watts
140 Watts
GAIN, Small Signal, Minimum 45 dB 46 dB
GAIN, Large Signal, Minimum 40 dB 40 dB
GAIN VARIATION, SSG
Narrow Band, Maximum
Full Band, Maximum
1.5 dB over any 40 MHz band
2.5 dB
1.0 dB over any 40 MHz band
2.5 dB
GAIN SLOPE, Maximum
±0.04 dB/MHz ±0.04 dB/MHz
GAIN STABILITY IN ANY 24
HOUR PERIOD, Maximum
±0.25 dB ±0.25 dB
GAIN STABILITY OVER
TEMPERATURE
±1.0 dB maximum over operating
temperature range at any frequency
±1.0 dB maximum over operating
temperature range at any frequency
INTERMODULATION WITH
TWO EQUAL SIGNALS
-18 dBc maximum with two equal carriers
at 4 dB total output backoff
-18 dBc maximum with two equal
carriers at 4 dB total output backoff
HARMONIC OUTPUT,
Maximum -60 dBc -60 dBc
AM TO PM CONVERSION,
Maximum
2.5°/dB at 6 dB below rated power 2.5°/dB at 6 dB below rated power
NOISE POWER
Transmit Band, Maximum
Receive Band, Maximum
-70 dBw/4 KHz
-150 dBw/4 KHz
3.7 GHz to 4.2 GHz
-80 dBw/4 KHz
-160 dBw/4 KHz
3.7 GHz to 4.2 GHz
GROUP DELAY, Maximum
Bandwidth
Linear
Parabolic
Ripple
Any 40 MHz
0.01 nS/MHz
0.005 nS/MHz
2
0.5 nS/Pk-Pk
Any 40 MHz
0.01 nS/MHz
0.005 nS/MHz
2
0.5 nS/Pk-Pk
RESIDUAL AM NOISE,
Maximum
-50 dBc to 10 KHz
-20 (1.5+log
f
) dBc 10 to 500 KHz
-85 dBc above 500 KHz
-50 dBc to 10 KHz
-20 (1.5+log
f
) dBc 10 to 500 KHz
-85 dBc above 500 KHz
PHASE NOISE, Maximum 10 dB below IESS phase noise profile
AC fundamental -50 dBc
Sum of all spurs -47 dBc
10 dB below IESS phase noise profile
AC fundamental -50 dBc
Sum of all spurs -47 dBc
VSWR, Maximum
Input
Output
1.3:1
2.2:1
1.3:1
2.2:1
