Detailed Description
See the Marvell Alaska Gigabit Ethernet Transceivers product page for more information.
[Ref 31]
Also, see the LogiCORE™ IP Tri-Mode Ethernet MAC User Guide (UG138). [Ref 19]
AM12 PHY_RXD4 124 RXD4
AD11 PHY_RXD5 123 RXD5
AC12 PHY_RXD6 121 RXD6
AC13 PHY_RXD7 120 RXD7
AH12 PHY_TXC_GTXCLK 14 GTXCLK
AD12 PHY_TXCLK 10 TXCLK
AH10 PHY_TXER 13 TXER
AJ10 PHY_TXCTL_TXEN 16 TXEN
AM11 PHY_TXD0 18 TXD0
AL11 PHY_TXD1 19 TXD1
AG10 PHY_TXD2 20 TXD2
AG11 PHY_TXD3 24 TXD3
AL10 PHY_TXD4 25 TXD4
AM10 PHY_TXD5 26 TXD5
AE11 PHY_TXD6 28 TXD6
AF11 PHY_TXD7 29 TXD7
A3 SGMII_TX_P 113 SIN_P
A4 SGMII_TX_N 112 SIN_N
B5 SGMII_RX_P 107 SOUT_P
B6 SGMII_RX_N 105 SOUT_N
Table 1-13: Ethernet PHYConnections (Cont’d)
U1 FPGA Pin Schematic Net Name
U80 M88E1111
Pin Number Pin Name
