ML605 Hardware User Guide www.xilinx.com 9
UG534 (v1.9) February 26, 2019
Chapter 1
ML605 Evaluation Board
Overview
The ML605 board enables hardware and software developers to create or evaluate designs
targeting the Virtex®-6 XC6VLX240T-1FFG1156 FPGA.
The ML605 provides board features common to many embedded processing systems.
Some commonly used features include: a DDR3 SODIMM memory, an 8-lane PCI
Express® interface, a tri-mode Ethernet PHY, general purpose I/O, and a UART.
Additional user desired features can be added through mezzanine cards attached to the
onboard high-speed VITA-57 FPGA Mezzanine Connector (FMC) high pin count (HPC)
expansion connector, or the onboard VITA-57 FMC low pin count (LPC) connector.
Features provides a general listing of the board features with details provided in Detailed
Description.
Additional Information
Additional information and support material is located at:
• www.xilinx.com/ml605
This information includes:
• Current version of this user guide in PDF format
• Example design files for demonstration of Virtex-6 FPGA features and technology
• Demonstration hardware and software configuration files for the System ACE™ CF
controller, Platform Flash configuration storage device, and linear flash chip
• Reference design files
• Schematics in PDF and DxDesigner formats
• Bill of materials (BOM)
• Printed-circuit board (PCB) layout in Allegro PCB format
• Gerber files for the PCB (Many free or shareware Gerber file viewers are available on
the internet for viewing and printing these files.)
• Additional documentation, errata, frequently asked questions, and the latest news
For information about the Virtex-6 family of FPGA devices, including product highlights,
data sheets, user guides, and application notes, see the Virtex-6 FPGA documentation page
at
www.xilinx.com/support/documentation/virtex-6.htm.
